30Amps high performance blade type discharge fuse 6Pins discharging plug with nickel-plating Waterproof grade: IP65 Self-development LED rear light Three levers LED capacity indicator DC2.1 charging Port optional 5Pin high current charging Plug Basic Characteristics Weight ≤ 3.9kg Working temperature Charge Temperature 0~45°C Discharge Temperature -20~65°C Retention of charge (store in one month) ≥95% Technical Data Rated Voltage 36V Rated Capacity C1 ≥ 15Ah Battery Resistance ≤100mΩ Charge Way of Charge CC/CV(Constant Current;Constant Voltage) Standard Charge Current 2A Max Charge Current 5A Max Charge Voltage 42V Cell OverCharge Protection Voltage 4.2V/Cell Discharge Standard Discharge Current 15A can be customized Max Discharge Current 20A can be customized Discharge Cut-off Voltage 30V Cell Overdischarge Protection Voltage 3.0V/cell Ratio Discharge 1C >96%C1 2C >93%C1 3C >90%C1 Cycle Life ≥ 800 Cycles
